4P 600V High Tro Reel System Low Power Mobile Devices Safety
Seamless Conductor Rail
Specifications
1. Low-Power Mobile Devices Safety Seamless Conductor Rail
2. Simple structure, easy for installation.
3. Current: 50~140A
Low-Power Mobile Devices Safety Seamless Conductor Rail, Low-Power
Mobile Devices Seamless Insulated Conductor Bar, Seamless Conductor
Rails, High Tro Reel System for overhead crane, light in weight,
simple in structure.
Quick Detail
- Rated value: 4P, 600V, 50~140A.
- Conductor material: Copper.
- Insulated sleeve material: UPVC(heat resistance: 75°C).
Detailed Product Description
Low-Power Insulated High Tro Reel Systems Seamless Conductor Bar
are used widely for workshops, ring application or slip rings,
stacking system and other industrial applications.
It is a new type of industrial mobile power feeding system, and the
most typical advantage is the light weight and tender nature, easy
for carry and install. The conductor bar has 3 poles and 4 poles
two choice, with a current capacity about 50A to 120A, especially
used to carry low power.
Low-Power Mobile Devices Safety Seamless Conductor Rail
Technical Parameters
Type | Poles | Conductor Cross Section(mm²) | Max. Current(A) | Order-NO. |
HTR1004 | 4 | 3×10+1×0.9 | 50A | 761004 |
HTR1504 | 4 | 3×15+1×1.0 | 80A | 761504 |
HTR2004 | 4 | 3×20+1×1.0 | 100A | 762004 |
HTR2504 | 4 | 3×25+1×1.2 | 120A | 725004 |
HTR3504 | 4 | 3×35+1×1.5 | 140A | 763504 |
HTR1003 | 3 | 3×10 | 50A | 761003 |
HTR1503 | 3 | 3×15 | 80A | 761503 |
HTR2003 | 3 | 3×20 | 100A | 762003 |
HTR2503 | 3 | 3×25 | 120A | 72500 |
HTR3503 | 3 | 3×35 | 140A | 763503
|
Quick Details Application
- Small power line feeding system.
- Overhead and elongated tracks for cranes.
- Electric hoists, electric tools, stacking systems.
- Electric tools
- Other applications for supplying power to moving power load.
Design features
1 safe, stable, non-interface (Apart from the supply point)
2 Small size, easy installation, economy
3 Copper and plastic is in close contact with the shock, won't
because shaken to caause sex poor, Stability, good performance
4 Insulators for vinyl chloride + impact resistance, UV resistance,
small size, easy installation, economy, special formula, physical
resistance.
5 Applicable to all kinds of curved electric hoist
6 To adopt THDW products in the short power distance, low
frequency, a better environment.
Tag : conductor rail system, crane conductor bar
