Anti - Explosion Festoon Cable Trolley Corrosion Resistance 2.45kg

    Buy cheap Anti - Explosion Festoon Cable Trolley Corrosion Resistance 2.45kg from wholesalers

    Buy cheap Anti - Explosion Festoon Cable Trolley Corrosion Resistance 2.45kg from wholesalers
    • Buy cheap Anti - Explosion Festoon Cable Trolley Corrosion Resistance 2.45kg from wholesalers

    Anti - Explosion Festoon Cable Trolley Corrosion Resistance 2.45kg

    Ask Lasest Price
    Brand Name : NANTE
    Model Number : W45AMC-150
    Certification : ISO9000
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 2000000 Piece/Pieces per Year
    Delivery Time : 15 working days after received your payment
    • Product Details
    • Company Profile

    Anti - Explosion Festoon Cable Trolley Corrosion Resistance 2.45kg

    I Beam Festoon System for Crane, H-Beam Festoon Cable Trolley, I Beam and Trolley, Stretched Wire Festoon System, I Beam Cable Carrier Large Round/Flat Cable, Festoon Cable System.

    Place of Origin: Zhejiang, China (Mainland)
    Brand Name: Nante
    Model Number: W45AMC-150
    Material: Galvanized steel
    Bearing: Ball bearing
    Travel Speed: <250m/min
    Temperature: -30℃ to +120℃
    Cable Load: Max.60kg
    Weight: 2.45kg
    Bumper: Neoprene

    Packaging & Delivery

    Packaging Details:Naked, Wooden case or Carton
    Delivery Detail:Within 15days

    Specifications

    1. Anti-explosion Festoon Cable Trolley on I Beam
    2. Delivering power&control to mobile equipment


    Detailed Product Description


    Anti-explosion Festoon Cable Trolley on I Beam, I Beam Festoon System for Crane, H-Beam Festoon Cable Trolley, I Beam and Trolley, Stretched Wire Festoon System, I Beam Cable Carrier Large Round/Flat Cable, Festoon Cable System.


    Detailed Product Description

    This series of I beam trolleys and components integrating our worldwide job proven flat cable provides a safe, efficient and maintenance free method of mobile electrification. The minimum bending radius permissible for lat cable is 5 times the thickness of the cable, thus allowing a considerably smaller bend radius compared to round cable of equal conductor size.


    Application

    Crane manufacturing, hoist units, transport systems, special engineering, stacking systems, conveyor system, etc. C-rails are available in zinc-coated and stainless steel version (program 230 to 240). Special versions are available for explosion-proof areas.


    Design features:

    Compact arrangement, elegent appearance.

    Corrosion resistance

    Simple assembly

    Easy for transportation and installation


    Technical Parameters


    TypeW35MC-70W35MC-120W35MC-150
    WheelsBall bearings, hardened, galvanized Temperature resistance: -30C to +120C
    Travelling speed: ca. 300 m/min.
    MaterialCarrier body: steel, galvanized Support saddle: steel, galvanized Bumper: Neoprene
    Dowel: steel, galvanized Hardware: galvanized
    Temperature resistance: -30°C to +120°C
    Max. cable loadmax.50KGmax.60KGmax.70KG
    Dim. of Cable (mm)max.75 Wx32δmax.120 Wx60δmax.150 Wx70δ
    Weight(kg)1.92.42.5

    Product Tags:

    I Beam Festoon System



    h Beam Trolley
