End Cap For HFP95 Series Enclosed Conductor Rail Poles 5,6,7,8,9,10 Max. Voltage 660V

    Buy cheap End Cap For HFP95 Series Enclosed Conductor Rail Poles 5,6,7,8,9,10 Max. Voltage 660V from wholesalers

    Buy cheap End Cap For HFP95 Series Enclosed Conductor Rail Poles 5,6,7,8,9,10 Max. Voltage 660V from wholesalers
    • Buy cheap End Cap For HFP95 Series Enclosed Conductor Rail Poles 5,6,7,8,9,10 Max. Voltage 660V from wholesalers

    End Cap For HFP95 Series Enclosed Conductor Rail Poles 5,6,7,8,9,10 Max. Voltage 660V

    Ask Lasest Price
    Brand Name : NANTE
    Model Number : HFP
    Certification : ISO9001, CE, CCC
    Payment Terms : L/C, T/T, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 1000000 pcs per year
    Delivery Time : 1-2 weeks
    • Product Details
    • Company Profile

    End Cap For HFP95 Series Enclosed Conductor Rail Poles 5,6,7,8,9,10 Max. Voltage 660V

    TypeWeight(kg)Material
    95EC0.05Plastic

    Specifications

    Sealed, waterproof, moisture
    Excellent resistance to UV and weather resistance Environmental standards: RoHS
    Working temperature: -55 ℃ ~ 110 ℃
    Shrink temperature: 80 ℃ ~ 120 ℃
    Standard color: black


    Test

    Test itemsPerformanceTest Methods
    Tensile Strength≥14MPaASTM D 412
    Elongation at break≥400%ASTM D 412
    Density1.05g/cm3ASTM D 792
    Aging elongation≥300%ASTM D 412
    Dielectric strength≥15kV/mmIEC 60243
    Volume resistance≥1014Ω .cmIEC 60093

    ModelPole No.Cross section
    (mm2)
    Max.current
    (A)
    Leakage-distance
    (mm)
    Max.voltage
    (V)
    Resistance
    (Ω)
    Weight
    (kg)
    HFP95-5-10/50101050206601.6563.2
    HFP95-5-15/80101580206601.1933.28
    HFP95-5-20/1001020100206601.0113.51
    HFP95-5-10/50101050206601.6563.16
    HFP95-5-15/80101580206601.1933.41
    HFP95-5-20/1001020100206601.0113.68
    HFP95-5-10/50101050206601.6563.25
    HFP95-5-15/80101580206601.1933.56
    HFP95-5-20/1001020100206601.0113.88
    HFP95-5-10/50101050206601.6563.34
    HFP95-5-15/80101580206601.1933.7
    HFP95-5-20/1001020100206601.0114.04
    HFP95-5-10/50101050206601.6563.42
    HFP95-5-15/80101580206601.1933.77
    HFP95-5-20/1001020100206601.0114.24
    HFP95-5-10/50101050206601.6563.54
    HFP95-5-15/80101580206601.1933.98
    HFP95-5-20/1001020100206601.011

    5.21


    Application


    The ranges of applications of HFP Power Rail Enclosed Conductor System

    1. Overhead and elongated tracks for cranes.

    2. Electric hoists, electric tools, stacking systems.

    3. Electric tools

    4. Other applications for supplying power to moving power load.

    Design features:

    Compact arrangement, corrosion resistance and simple assembly are its essential features.


    Housing

    Color green, PVC housing for 4 conductors. Standard section 4 m.

    Other sections are available.

    The ground conductor is identified by international color code.

    Phase reversing prevented by design of the collector and housing.


    Current collectors

    The current collectors are made of re-inforced polyester fiberglass,for high strength and light weight.

    Spring loaded carbon brushes maintain uniform contact.

    Connecting cables and hinged or flexible towing arms included.

    Double Current collectors for transfer applications and higher amperage.

    HFP Series Multiple-Poles Conductor Rail System
    Max. voltage600vBending strength75N/mm²±10%
    Dielectric strength30-40kv/mmTensile strength40N/mm²±10%
    Special resistance5×1015 Ohm×cmLeakage resistanceCTI600-2,7
    Surface resistance1013 Ohm×cmDesign and Manufacturing StandardGB7251.2-2006
    Distance between each suspension bracket (m)1.2Rail length per piece (m)4
    Flame retardantClass B1-no flaming particles, self-extinguishing
    Permissible Ambient temperatureStandard insulation -30°C- +70°C|High temperature insulation -20°C- +115°C|Low temperature insulation -40°C- +80°C

    Specifications

    Sealed, waterproof, moisture
    Excellent resistance to UV and weather resistance Environmental standards: RoHS
    Working temperature: -55 ℃ ~ 110 ℃
    Shrink temperature: 80 ℃ ~ 120 ℃
    Standard color: black
