Detailed Product Description

Round Flat Crane Cable With Steel Wires 24c 16 AWG 24 x 1.5

Structure:

Conductor: fine strands of oxygen-free copper wire

Acc. To Vde0295, class 5

Colour: various colour cores with number acc.to JISC3306

Black with white number and green/yellow

Inner liner: non-woven fabric wrapping to release impact.

Steel rope: one or two self- supporting steel ropes is used to carry tensile force in working.

Outer sheath: special PVC, black (RAL9005)

Pendant control cables, 300 rated voltage pendant cables, chain hoist pendant cable, crane pendant cable, round lift/crane pendant cable with steel supporting, pendant cable elevator cable reeling portable flexible crane cable, high quality pendant control cables, single girder overhead crane cables, round cable with supporting steel wires.

Applications:

It’s the control cable being used for cranes and other appliances in dry or wet environment( in –door). For it’s special flexibility, it also can be used for non-continuous installation or fixation, but can’t work as elevator cables, juted insulated cable rope among cores functions as tensile resistance, there is non-woven fabric to release impact between cores and sheath.

Properties:

In the condition of ultra-height, we recommend to use cable with 2 steels whose broken pulling force reaches 10.4KN and the height 150m. for the adoption of modified PVC sheath, the product has an excellent properties and safety service.

Technical data:

Rated voltage: ≤ 1.5mm: 300/500V ≥ 1.5mm: 450/750V

Test voltage: ≤ 1.5mm: 2500V ≥ 1.5mm: 3000 V

Temperature range: -15℃ to +70℃

Bending radius: 20 x outer diameter

specification parameter

NANTE:

After 20 years rapid development, NANTE and its parents company ZHONGJIAN Group has grown into a leading integrated solution provider for crane and crane components in China.  Dedicated to the research and development of new lifting and handling technologies, we adopt innovative ideas and design in developing new products and services. Backed up by a wealth of industrial experience on lifting industry, WE can provide to customer wide range of lifting equipment and components with scientific design, good safety, high performance, efficient operation and low maintenance cost.  We are committed to help our clients to reduce investment cost, improve production efficiency, and economize energy consumption.

OUR PRODUCTS:

In order to offer our clients with a complete set of competitive lifting solution. WE delivers a wide range of products include:

1. Lifting Equipments for Construction: Beam Launcher, Gantry Crane, Segment Lifter, Form Traveler, and Bailey Bridge etc.

2. Lifting Equipments for Industry: Overhead Crane, Gantry Crane, Jib Crane, Light Crane System.

3. Crane Components: Electric Hoist & Trolley, End carriage, Conductor Rail, Festoon system, Steel Rail, Flat cable, Pendent control, geared motor, remote control etc.

Our Service

WE can provide to customer an integrated solution which includes project consultant, design, manufacturing, transportation, installation, maintenance and technical support. Our one-stop services can not only save our customers time but also minimize their cost.

In compliance with our service concept “Customer First”, we provide the following support services to ensure smooth running of customer’s lifting and handling equipments: Presale Technical Support, After-sale Maintenance, Spare Parts Support, and Customized Solutions.
